This series accuracy pyrometer have the function of switching between one-color and two-color modes and is rarely affected by emissivity of the measured object, and displayed temperature is basically unchanged even if the target signal decays 95%. This 2-color pyrometer use adjustable focus lens, with high-brightness green LED light source or visual eyepiece aiming, and clearly display the position and size of the measured target. This series infrared thermometer use industrial-grade OLED screen as the display interface, which is user-friendly.
Measuring range：450℃～2500℃
Detector：InGaAs/InGaAs（Laminated Indium Gallium Arsenic）
Distance coefficients：200：1
Measuring Distance：Standard Focus length：0.35m adjustable to infinity，Near focus distance：0.2m～0.5m
Accuracy：±0.5%T℃（T is measured temperature）
Resolution：0.1℃
Repeat Accuracy：±2℃
Response time：Fasted 5ms, adjustable in 5ms-99.99s
Model | STRONG-GR-4525 |
Measuring Range | 450℃～2500℃ |
Detector | InGaAs/InGaAs（Laminated Indium Gallium Arsenic） |
One-color mode Wavelength | 1.7μm |
Two-color mode Wavelength | Wavelength1：（0.9～1.7）μm Wavelength 2：1.7μm |
Applications | High accuracy, highly stable Two color Infrared Pyrometer, applied to metallurgical industry（rod and wire mills, Hot rolling mills）, foundry, cement kiln, induction heating, heat treatment, heating furnace, vacuum furnace, monocrystalline silicon, polysilicon, semiconductor and other industrial temperature measurement. |
Distance coefficients | 200：1 |
Focal length | Standard：0.35m adjustable to infinity， Near focus distance：0.2m～0.5m |
Accuracy | ±0.5%T℃（T is measured temperature） |
Resolution | 0.1℃ |
Repeat Accuracy | ±2℃ |
One-color mode: Calibration coefficient | 0.100～1.000, Adjustable in 0.001 increments |
Two-color mode: Calibration coefficient | 0.850～1.150, Adjustable in 0.001 increments |
Response time | Fasted: 5ms，adjustable in 5ms-99.99s |
Display mode | Industrial-grade self-luminous OLED display screen |
Aiming method | Visual green spot (default) or eyepiece aiming, alternative |
IP Rating | IP65 |
