It uses the manual adjustable focal length, achromatic lens, high reliability circuit design (low temperature drift, full digital measurement design, high integration SOC chip application, visualize OLED operation interface) and software design (ambient temperature compensation, real-time signal processing, abnormal signal processing, software code optimization in all kinds of application environment ).These special designs enable the STRONG series of one-color pyrometers to meet the use in a variety of harsh industrial field and precise temperature control requirements.
STRONG series one color pyrometer determine the object temperature by receiving the sum of the narrow-band radiation energy emitted by the object. It uses advanced software and hardware design, with ultra-wide dynamic range and high stability.
It can be widely used in metallurgical industry (wire rod, hot rolled plate, forging) and forging industry, heat treatment, induction heating, single crystal silicon, polycrystalline silicon and various occasions of industrial temperature measurement.
Measuring range：700℃～3000℃
Detector：Si
Distance coefficients：100：1
Measuring Distance：Standard Focus length：0.35m adjustable to infinity，Near focus distance：0.2m～0.5m
Accuracy：±0.5%T℃（T is measured temperature）
Resolution：0.1℃
Repeat Accuracy：±2℃
Response time：Fasted 5ms, adjustable in 5ms-99.99s
Model | STRONG-S-7030 |
Measuring Range | 700℃～3000℃ |
Detector | Si |
Wavelength | (0.85～1.1）μm |
Applications | High accuracy, highly stable One color Infrared Pyrometer,applied to induction heating, heat treatment, monocrystalline silicon furnace, polysilicon furnace, vacuum furnace, melting glass, forging and other industrial temperature measurement. |
Distance coefficients | 100：1 |
Focal length | Standard：0.35m adjustable to infinity， Near focus distance：0.2m～0.5m |
Accuracy | ±0.5%T℃（T is measured temperature） |
Resolution | 0.1℃ |
Repeat Accuracy | ±2℃ |
Calibration coefficient | 0.100～1.000, Adjustable in 0.001 increments |
Response time | Fasted: 5ms，adjustable in 5ms-99.99s |
Display mode | Industrial-grade self-luminous OLED display screen (default) or visual eyepiece aiming |
Aiming method | Visual green spot (default) or eyepiece aiming, alternative |
IP Rating | IP65 |
